Swan 78

Design

The architect

German Frers

All of Nautor´s know-how and experience in racing and cruising yachts have been incorporated into this new blue-water Swan 78, a direct descendant of the original Swan 80 and 82 models of the past. She is slightly shorter overall – in order to meet the EC 24.00 metre length overall limitation – beamier and more powerful. The modern hull lines, including a wide stern above the waterline, twin rudders and racing oriented keel design, are a reflection of the rapid evolution of yacht design during the past years, propelled by the experiences made on round-the-world races and other offshore events. The new boat is faster, safer, easier to control and, as a result, more comfortable at sea. The keel options include deep telescopic lifting, fixed deep and fixed shallow possibilities yet maintaining stability, the same rudder configuration and standard sail plan.
The same could be said of the deck with its modern design, uncluttered surfaces and straightforward, simple solutions to sail handling and life at sea. The appearance is that of neatness and efficiency. Two options are offered for the interior, Owner Forward and Owner Aft. Centered around the main saloon and engine room, which maintain the same position facilitating weight distribution, planning of installations and flotation trim, both layouts share the same number of cabins: one double berth VIP and two twin berth layouts.
These are slightly favoured in the Owner Forward version which allows for side by side bunks on the second and third guest rooms. Crew accommodations for two are ample and functional in both cases. This new Swan is, and will be, the best of her kind for years to come.

Standard

Square top main option

Deck

The deck is the one area of the yacht where owners, guests and crew spend the most time. Here is where the yacht is handled under sail, and here is where guests enjoy the seascapes at anchor. The Swan 78 deck layout is the most recent evolution of the “S” concept (Semi-raised Saloon), with the celebrated Swan coachroof, discreet and streamlined, with panoramic views from inside, due to the raised saloon. On the 78 Frers signature lines have given their very best, with sleek curves that create a volume capable of protecting the cockpit and creating more space below. The coachroof design is a masterly mix of curved lines and multifaceted surfaces, with 360 degree windows and a generous roof that doubles up as a sunbathing area. The recessed sprayhood and the full beam bimini keep guests always well protected in a cockpit/lounge that features two C shaped settees each with its own table.

All manoeuvres are at the centre of the cockpit and can be handled easily by a reduced crew. The five available winches are well placed around the helm stations with a central tower dedicated to the mainsheet. As an option, a captive winch for main sheet can be provided.

Further aft the deck is equipped for sunbathing and swimming, with a completely open space than can be equipped with cushions and access to the beach area, which also opens a full beam lazarette that can stow a rigid inflatable.

Forward of the mast the deck is completely uncluttered, an expanse of pure teak that ends at the forepeak with the large locker for the anchor.

Owner AFT

Owner FWD

Interior

The interior designer

Heini Gustafsson

To provide the most flexibility and satisfy any possible owners’ requirement, the interiors of the Swan 78 are offered in two exclusive and different layouts: Owner Forward and Owner Aft. In the first configuration, the Owner has a large suite forward, cooler and quieter. It is 4.5 m long, with an island bed that is completely accessible on three sides. A desk and dedicated bathroom, with large separate shower compartment, complete this luxurious apartment. The Owners Aft version is dedicated to owners who wish to sail long distances and in any weather. The large suite, in this case, is placed to the stern, in the area where there is less movement and less noise under sail. The cabin provides an impressive 6 m width, thanks to the generous volumes of the innovative hull.

Whichever the version, the accommodation also features three guest cabins with different layouts, all ensuite with separate shower compartments. The saloon remains the same in both versions, and it is also over 6 m wide. It is raised to provide better panoramic views. Below, ample bilge volumes allow for a full beam engine room, totally soundproofed and large enough to accommodate a variety of systems and equipment. The crew quarters are separate, forward or aft according to the chosen layout, with an ensuite cabin. The galley is in the same area, with large cooking areas and refrigerated stowage.

The celebrated Nautor finish guarantees top quality both in the technical details and in the finishing, with a wide choice of veneers and accessories.

Owner AFT

Owner FWD

Sailing

Sailing a Swan 78 is an experience that instantly explains the latest design trends for sailing yachts. The first feature that emerges is her extreme stability during sailing, made possible through her twin rudders. Indeed, as heel angle increases, the geometry in the water alters to adapt to the new position. The windward rudder lifts while the leeward one dips progressively, becoming more perpendicular and at the same time more efficient. Heeling stability is guaranteed – with the first few degrees of heel, the hull form facilitates prompt acceleration even in light conditions. Heel angle stabilises at around 20 degrees, remaining symmetrical and balanced throughout. Beyond this inclination, the hull shape contributes dynamically to the vertical force provided by the T-shaped keel, maintaining the optimal hull position.

All this translates into two fundamental and apparently opposite effects. These are that performance is optimised keeping the hull sailing to its lines and therefore all the naval architecture including keel and rudders at maximum efficiency, and at the same time the yacht remains comfortable and liveable, allowing life on board to continue normally even when sailing upwind for long distances. If her performance off-wind appears obvious, the new Swan 78 amazes even more upwind. Perfect balance translates into unexpected agility, with the helms remaining light. The rudders, almost always at centre, are only necessary for changing course. This allows those on board to play amongst the waves and promptly follow wind shifts. The Swan 78 allows her crew to sail at double digit boat speeds constantly and safely, easily managing manoeuvres from around the twin helms. At anchor, the various areas for relaxing, protected from or immersed in the elements, allows those on board to fully enjoy the surrounding scenery.

Specifications

Length overall23,99 m 78.70 ft
Length of waterline22,18 m 72.77 ft
Beam max6,40 m 21.00 ft
Draft4.00 m 13.12 ft
Draft shallow (opt)3.00 m 9.84 ft
Draft lifting keel (opt)3.00 m/4.30 m 9.84 ft /14.11 ft
Displacement42.600 kg 93,916 lbs
Ballast11.600 kg 25,573 lbs
Engine140 kW 190 Hp
IG31,60 m 103.67 ft
J9,77 m 32.05 ft
P31,00 m 101.71 ft
E10,25 m 33.63 ft
Main sail196,0 m2 2110 sq.ft
Fore triangle154,4 m2 1662 sq.ft
Jib174,3 m2 1876 sq.ft
Fuel2.000 l 528 gal
Water1.300 l 343 gal
DIMENSIONS
Length overall23,99 m 78.70 ft
Length of waterline22,18 m 72.77 ft
Beam max6,40 m 21.00 ft
Draft4.00 m 13.12 ft
Draft shallow (opt)3.00 m 9.84 ft
Draft lifting keel (opt)3.00 m/4.30 m 9.84 ft /14.11 ft
Displacement42.600 kg 93,916 lbs
Ballast11.600 kg 25,573 lbs
Engine140 kW 190 Hp
RIG AND SAIL DIMENSIONS
IG31,60 m 103.67 ft
J9,77 m 32.05 ft
P31,00 m 101.71 ft
E10,25 m 33.63 ft
Main sail196,0 m2 2110 sq.ft
Fore triangle154,4 m2 1662 sq.ft
Jib174,3 m2 1876 sq.ft
TANK CAPACITY
Fuel2.000 l 528 gal
Water1.300 l 343 gal
